CONDUCTIVE FABRIC TAPE / CSTK Thin and durable carbon-coated type
CSTK / Conductive Fabric Tape
Thin and durable carbon-coated typeAusführungen
Features
- Carbon-coating protects from the galvanic corrosion suffered by metal foils.
- Carbon-coated special knitting provides no yarn-loosening or fuzz on the surface.
- Carbon-coated tape with low resistivity, effective against electrostatic discharge.
| Part No. | (mm) Width | (mm) Thickness | adhesive strength | Resistivity |
|---|---|---|---|---|
| CSTK-008 | 8 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-015 | 15 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-020 | 20 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-025 | 25 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-030 | 30 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-040 | 40 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-060 | 60 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-250 | 250 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
| CSTK-300 | 300 | 0.1 | 8.53 N/25mm/Width | 0.04 Ω/20mm |
※ The values are measured data for reference, not guaranteed.
Download
Data sheet with all relevant information on dimensions, material, and electrical properties. Ideal for design, selection, and comparison.
Further data sheets, test reports, and 3D drawings can be found in the download area of Kitagawa Industries.
