COLLAR BUSH／KCB-310-V0
KCB-310-V0 / Collar Bush
Ausführungen
Features
- One-piece structure for good workability.
- Screw fixing is suitable for installing heavy PCBs.
- The bush covers screwheads to protect and insulate the screw.
Material
- PA66（Color：Natural), UL flammability class：UL94－V0
| Collar No. | Mounting hole | Panel thickness | Applicable screw | Recommended torque |
|---|---|---|---|---|
| KCB-310-V0 | ∅6.6±0.1ｍｍ | t1.6±0.1ｍｍ | 3 pan head screw(JIS B1111) | 0.686～0.784Ｎ・ｍ |
Download
Data sheet with all relevant information on dimensions, material, and electrical properties. Ideal for design, selection, and comparison.
